Van Điều Áp KVP, KVL, KVRVan điều áp KVP 15 – C/N: 034L0022
2.900.000₫ Giá sau thuế VAT: 3.132.000₫
Van điều áp KVP 15 (ren 5/8″; 16mm)
- Type: KVP 15
- Mã sản phẩm: 034L0022
- Kiểu kết nối: Flare
- Connection size: 5/8 in, 16 mm
- Thương hiệu: Danfoss
- Xuất xứ: Danfoss Poland
Thời gian bảo hành: 12 tháng.
Thuế VAT: Mức thuế VAT sẽ được xác định theo luật quy định của Nhà nước tại thời điểm Tâm Phúc phát hành hóa đơn VAT.
Evaporator pressure regulator, KVP 15
034L0022
- Inlet size [mm]: 16.00
- Outlet size [mm]: 16.00
- Inlet size [in]: 5/8 in
- Outlet size [in]: 5/8 in
- Inlet connection type: Flare
- Outlet connection type: Flare
- Kv value [m³/h]: 2.500
- Max. Working Pressure [bar]: 18.0
Thông số kỹ thuật Van điều áp KVP 15 – 034L0022
Gross weight |
0.468 Kilogram |
Net weight |
0.42 Kilogram |
EAN |
5702428411875 |
|
Type |
KVP 15 |
Product group |
Press. and temp. regul. valves |
Product Name Description |
Evaporator pressure regulator |
|
Approval |
C UL US LISTED
EAC
LLC CDC TYSK |
Approval file name |
REFRIGERANT VALVE 53R0 |
China RoHS compliance |
Yes |
Contain batteries |
No |
Cv value [gal/min] |
2.9 gal/min |
Equipment |
Schrader valve access port |
EU RoHS compliance |
Yes |
EU RoHS exemption clause |
No |
Factory setting [bar] |
2 bar |
Factory setting [psig] |
29 psig |
Flow direction indicator |
Engraved 1-way arrow |
Inlet connection type |
Flare |
Inlet size [in] |
5/8 in |
Inlet size [mm] |
16 mm |
Kv value [m³/h] |
2.5 m³/h |
Kv value note |
AT MAX P-BAND |
Lubricants compatibility |
Oilfree applications |
Max. test pressure [bar] |
19.8 bar |
Max. test pressure [psig] |
286 psig |
Max. Working Pressure [bar] |
18 bar |
Max. Working Pressure [psig] |
260 psig |
Medium temperature range [°C] [max] |
130 °C |
Medium temperature range [°C] [min] |
-45 °C |
Medium temperature range [°F] [max] |
266 °F |
Medium temperature range [°F] [min] |
-49 °F |
Oil free refrigerants |
R1234ze(E)
R513A |
Other RoHS documentation |
EAEU RoHS |
Outlet connection type |
Flare |
Outlet size [in] |
5/8 in |
Outlet size [mm] |
16 mm |
P band max. [bar] |
1.7 bar |
P band max. [psi] |
24.6 psi |
|
Packing format |
Multi pack |
Product accessories |
No |
Quantity per packing format |
12 pc |
Rated cap. R404A/R507A [kW] |
3.6 kW |
Rated cap. R404A/R507A [TR] |
1.2 TR |
Rated capacity R134a [kW] |
2.8 kW |
Rated capacity R134a [TR] |
0.9 TR |
Rated capacity R22 [kW] |
4 kW |
Rated capacity R22 [TR] |
1.3 TR |
Rated capacity R407C [kW] |
3.7 kW |
Rated capacity R407C [TR] |
1.2 TR |
REACH Candidate List substances |
Lead (CAS no. 7439-92-1) |
Refrigerants |
R1234yf; R1234ze(E);
R134a; R22;
R404A; R407A;
R407C; R407F;
R407H; R422B;
R422D; R448A;
R449A; R449B;
R450A; R452A;
R454A; R454C;
R455A; R507A;
R513A; R515B;
R516A |
Regulation range [bar] [max] |
5.5 bar |
Regulation range [bar] [min] |
0 bar |
Regulation range [psig] Pe [max] |
80 psig |
Regulation range [psig] Pe [min] |
0 psig |
SCIP dossier no. |
842c526f-b213-4baa-869c-a91bb999a318 |
Serviceable |
KV valves spare parts |
UL approved refrigerants |
R134a
R22
R404A
R407A
R407C
R407F
R407H
R422B
R422D
R448A
R449A
R449B
R450A
R452A
R507A
R513A
R515B |
UL evaluated |
Yes |
|
Tâm Phúc chuyên cung cấp đa dạng các sản phẩm Van điều áp Danfoss chính hãng, đảm bảo chất lượng cao, giá cả cạnh tranh cùng dịch vụ chuyên nghiệp.
